DTC
C1119
Engine control system
DETECTION CONDITION
• Engine RPM information through CAN is out of specification
• Throttle information through CAN is out of specification
POSSIBLE CAUSE
• Malfunction of PCM
• Malfunction of CAN
DTC C1119 [DSC]
id040220874000
|
DTC
|
C1119
|
Engine control system
|
|
|
DETECTION CONDITION
|
• Engine RPM information through CAN is out of specification
• Throttle information through CAN is out of specification
|
||
|
POSSIBLE CAUSE
|
• Malfunction of PCM
• Malfunction of CAN
|
||
|
|||
Diagnostic procedure
|
STEP |
INSPECTION |
ACTION |
|
|---|---|---|---|
|
1
|
INSPECT FOR PCM FOR DTCs
• Turn ignition key to OFF.
• Connect WDS or equivalent to DLC-2
• Turn ignition key to ON (engine OFF).
• Is DTC for engine control system obtained?
|
Yes
|
Go to the applicable DTC inspection.
(See DTC TABLE [L8, LF, L3].)
(See DTC TABLE [L3 Turbo].)
|
|
No
|
Go to next step.
|
||
|
2
|
MONITOR CAN SIGNAL
• Access PID RPM and TP using WDS or equivalent.
• Are engine speed and throttle position within specification?
|
Yes
|
Go to next step.
|
|
No
|
Follow inspection procedures for engine control system.
|
||
|
3
|
VERIFY TROUBLESHOOTING COMPLETED
• Make sure to reconnect all disconnected connectors.
• Clear DTC from memory.
(See Clearing DTCs Procedures.)
• Start engine.
• Is the same DTC present?
|
Yes
|
Replace DSC HU/CM.
|
|
No
|
DTC troubleshooting completed.
|
||
